Quick Details

  • Light Source: LED
  • LED Light Source: Tianxin
  • Type: Moving Head Lights
  • Input Voltage(V): AC100-240V 50/60Hz
  • Lamp Power(W): 240
  • Lamp Luminous Flux(lm): 10000
  • Color Temperature(CCT): Cool White
  • Working Temperature(℃): -20 - 40
  • Working Lifetime(Hour): 50000
  • IP Rating: IP33
  • Certification: CE, EMC, LVD, RoHS
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: V-SHINY
  • Model Number: VSL-ZOOM BEE EYE 15W19 QUADLED RGBW
  • Emitting Color: RGBW 4-in-1
  • Voltage: AC100-240V 50/60Hz
  • Display: LCD display
  • Channel: 21/35/78/98/92CH
  • Power connect: Powercon in&out
  • DMX512: 3/5-pin XLR IN-OUT sockets
  • Color temperature: 2500 - 8000 k
  • warranty: 1 year
  • keyword: multi pattern mini laser stage lighting
  • Selling point: colorful beam, silent movement, perfect zoom effect
  • certificate: CE&ROHS

Packaging & Delivery

Packaging Details Packing Size: 47*35*51cm Gross Weight: 17.5kgs
Flight Case: Single, 2-in-1 for customers choice
Delivery Time 5-10 working days

12W19 RGBW multi pattern mini laser stage lighting

Product Description





POWER SUPPLIES

100-240V 50/60Hz

INPUT POWER

450VA

LAMP SOURCE

19 Osram Ostar RGBW LEDs
LED Nominal Wattage: 15W
LED Average Life: 50,000 h

OPTICS

4°-60° Electronic Zoom Range

EFFECTS SECTION

Three operating modes: wash, beam, FX (Kaleido effects)
Rotating Front Lens
Digital Wash-Beam Framing effect
Beam edge softening control (in Wash mode)
Pixel Patterning Macros with enhanced control
0-100% linear electronic dimmer
Adjustable speed stop/strobe effect, with instantaneous blackout
Dedicated channel for color temperature setting
White CT Emulation 2500-8000K
RGBW auto-tuning to lamp CT Emulation
Tungsten Lamp Emulation
Slow Strobe: 1 flash/sec
Fast Strobe: 25 flash/sec

CONTROL AND PROGRAMMING

Control channels: 21CH, 35CH, 78CH, 92CH and 97CH
Protocol signal: USITT DMX 512
Art-Net / RDM
Display: Graphic LCD backlit b/w Display
Pan/Tilt Resolution: 16 bit
Dimmer Resolution: 16 bit
Movement control:
vectorial
DMX signal connection:
3 pin XLR input and output
Software upload through DMX input



BODY

Aluminium structure with die-cast plastic cover
Two side handles for transportation
PAN lock for transport and maintenance

MOVING BODY

Movement by means of two stepper motors, controlled by microprocessor
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit
Travel:
- PAN = 540°
- TILT = 210°

ELECTRONICS

Long-life auto-charging buffer battery
Preset color and graphic effect macros
Function reset controllable from a central control unit
Menu-driven internal self-test function
Display:
LCD display with Touch Screen Panel
Electronic check-up of every single parameter with error alarm
DMX level monitoring on each channel
Automatic internal data transmission error diagnostics
Firmware upgrade even when the unit is not connected to the power supply
Firmware transfer from one light to another

SAFETY DEVICES

Automatic power safety derating in case of overheat of the LED board
Forced ventilation

WORKING POSITION

Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base

WEIGHT

15 Kg (33.1 lbs)













VSM-280

BEAM SPOT

1.Wheel, with 9 bidirectional and indexable gobos (outside diameter15,4 mm, image diameter 13 mm)

2.6-facet linear prism rotating in both directions at different speeds

3.parallel beam angel 2.5°-20° change

4.can open the lamp and reset, including delaying function













DMX ATOMIC

 STROBE 3000

consecutive blind effect can Gradate change, Intelligentize heat energy control to reduce cooling time,Strobe speed, brightness and

frequency can adjust,it also can edit special effect.











VSL- FLAT PAR 15W9

 RGBWA5-IN-1

1.The battery can last for 4-5 hours when all LED on after full charge , and can last for more than 6-8 hours on auto running mode.

Up to 20 Hours with one color diode on. Results will vary based on brightness of LED

2.It is suggested to charge the battery for at least 4 hours, which will extend the life span of the battery

3.Light is applicable to all kinds of stage, dance halls, discos, bars, hotels,theaters, night club, KTV, concerts and other places of

entertainmen
